Quick Details

  • Place of Origin: Hunan, China (Mainland)
  • Brand Name: Holykell
  • Model Number: HPT300-S
  • Pressure type: Gauge Pressure Absolute Pressure Sealed Pressure
  • Pressure range: -1 Bar-0-1 Bar; 0-0.1Bar...600 Bar / 0-2 Psi...15000 Psi Optional
  • Accuracy: 1%FS,0.5%FS
  • Power supply: 24VDC 12VDC 5VDC 12-36VDC
  • Output: 4-20mA, 0-5V, 0-10V,0.5-4.5V
  • Process connection: : 7/16-20UNF male ,7/16-20UNF female , G1/4" male, 1/4"NPT male
  • Response time: ≤20ms
  • workingtemp: -30~85C
  • Certification: CE
  • Warranty: 1 year ,and free repair for quality itself

Packaging & Delivery

Packaging Details 500psi Pressure Transducer: standard export packing, no damage to product
Delivery Time 10-15 days after payment
500psi Pressure Transducer or Sender for Oil,Fuel,Diesel,Gas,Air,Water.
pressure sensor Accuracy:1%F.S.



Product Description



Why Choose Our OEM Ceramic Pressure Sensor?

a.Low cost compact type

b.Imported Germany technology Ceramic sensors, 5-10 years design

c.Military level of printer PCB board, Anti-Jamming enhanced 300%, Stability of Circuit>10 years

d.Linear Amplified Output

e.Automatic temperature compensation -40~80,

   Temperature drift Automatic modified linear  ≤0.01%FS

f.Superior Long term Stability

g.Excellent Repeat ability/Hysteresis

h.EMI/RFI Rejection

i.Low power consumption

j.Ten million cycle life expectancy

k.Outstanding shock& vibration performance


Saving Money



We have many projects about water supply system successful case in the worldwide . Learn more ...

Holykell A whole sets of measurement solution is your smart choice .

Don't heasitate to contact us freely !!!



Core Competence





TECHNICAL PARAMETER

Pressure Range

-1-0-1 Bar.....600 Bar Optional

Accuracy

≤ ±1.0%F.S   ≤ ±0.5%F.S   ≤ ±0.25%F.S (Customized)

Diaphragm material

Piezoresistive Flush Ceramic

Electronic Wire

2 Wires

3 Wires

Output

4~20mA

0~5V

0~10 V

0.5~4.5 V

By Customized

Power Supply

12~36 V DC

12~36 V DC

15~36Vdc

5 V DC

By Customized

Insulate resistance

>100M Ω  @50V

Electronic connection

Terminal Box (DIN43650 Hirschman Connector, IP65)

Directly sealed cable IP67;

M12 4 Pins connector IP65;

Small Hirschman Connector; connection are optional.

Pressure connect port

1/8’’NPT male, 1/4’’NPT male

1/4’’NPT Female, G1/2’’ male, G1/4’’male/female,

7/16’’-20 UNF male/female are optional. (by Customized)

Response time

≤10ms

Certificate approving

CE Certificate.

EMC Standard

electromagnetic radiation:EN50081-1/-2

electromagnetic susceptibility:EN50082-2

Water Proof

IP65 to IP67

Weight

Net weight is about 0.10KG, Full Packing weight is about 0.5KG (Included 3 Meters Cable)



   Order information : Pressure range :0-10 bar , Output :4-20mA , Power supply:12~36VDC ,

                                  Process connection: 1/8"NPT male  ,Electronic Connector:Directly cable

What is The Application of Pressure Sensor ?



Our Services



If you purchasing now , we can assure within 24 hours release the cargo (normal spec.),

Customized 7-12 days after your payment .

Don t hesitate to place a new order now .

Company Information

How to order

  Inquiry information



In order to recommend you the most suitable pressure transmitter and make an accurate quotation, please provide the following information and send it to our sales when you are going to make an inquiry, thanks !



FAQ



Q:Can you accept ODM & OEM service ?

A:We professional provide OEM &ODM service for pressure transducer.

Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.

Q:How about the quality of the magnets?

A:We have the certification of ISO,CE and ROSH,we could send the certification test of our company to you.

Q:How is the price?
A:As we believe the quality is the most important,we will provide the best quality pressure sensor we can with reasonable price.
Q:Could you provide me the shortest lead time?
A:We have materials in our stock,if you really need,you can tell us and we will try our best to satisfy you.
Q:Could I visit your factory?
A:Of course,if you need we will help you to visit our factory.
